可视化




std::vector<ops::HolovizOp::InputSpec> input_specs;

auto& geometry_spec =
    input_specs.emplace_back(ops::HolovizOp::InputSpec("point_tensor", ops::HolovizOp::InputType::POINTS));
geometry_spec.priority_ = 1;
geometry_spec.opacity_ = 0.5;

auto& image_spec =
    input_specs.emplace_back(ops::HolovizOp::InputSpec("image_tensor", ops::HolovizOp::InputType::IMAGE));
image_spec.priority_ = 0;

auto visualizer = make_operator<ops::HolovizOp>("holoviz", Arg("tensors", input_specs));

// the source provides two tensors named "point_tensor" and "image_tensor" at the "outputs" port.
add_flow(source, visualizer, {{"outputs", "receivers"}});





namespace viz = holoscan::viz;

viz::Begin();

viz::BeginGeometryLayer();
viz::LayerPriority(1);
viz::LayerOpacity(0.5);
/// details omitted
viz::EndLayer();

viz::BeginImageLayer();
viz::LayerPriority(0);
/// details omitted
viz::EndLayer();

viz::End();





std::vector<ops::HolovizOp::InputSpec> input_specs;

auto& image_spec =
    input_specs.emplace_back(ops::HolovizOp::InputSpec("image", ops::HolovizOp::InputType::IMAGE));

auto visualizer = make_operator<ops::HolovizOp>("holoviz", Arg("tensors", input_specs));

// the source provides an image named "image" at the "outputs" port.
add_flow(source, visualizer, {{"output", "receivers"}});





viz::BeginImageLayer();
viz::ImageHost(width, height, format, data);
viz::EndLayer();





namespace viz = holoscan::viz;

viz::BeginGeometryLayer();

// draw a red rectangle
viz::Color(1.f, 0.f, 0.f, 0.f);
const float data[]{0.1f, 0.1f, 0.9f, 0.9f};
viz::Primitive(viz::PrimitiveTopology::RECTANGLE_LIST, 1, sizeof(data) / sizeof(data[0]), data);

// draw green text
viz::Color(0.f, 1.f, 0.f, 0.f);
viz::Text(0.5f, 0.5f, 0.2f, "Text");

viz::EndLayer();





std::vector<ops::HolovizOp::InputSpec> input_specs;

auto& depth_map_spec =
    input_specs.emplace_back(ops::HolovizOp::InputSpec("depth_map", ops::HolovizOp::InputType::DEPTH_MAP));
depth_map_spec.depth_map_render_mode_ = ops::HolovizOp::DepthMapRenderMode::TRIANGLES;

auto visualizer = make_operator<ops::HolovizOp>("holoviz",
    Arg("tensors", input_specs));

// the source provides an depth map named "depth_map" at the "output" port.
add_flow(source, visualizer, {{"output", "receivers"}});





sudo systemctl stop display-manager





sudo systemctl start display-manager





auto visualizer = make_operator<ops::HolovizOp>("holoviz",
    Arg("use_exclusive_display", true), // required
    Arg("display_name", "DP-2"), // optional
    Arg("width", 2560), // optional
    Arg("height", 1440), // optional
    Arg("framerate", 240) // optional
    );





const std::shared_ptr<holoscan::CudaStreamPool> cuda_stream_pool =
    make_resource<holoscan::CudaStreamPool>("cuda_stream", 0, 0, 0, 1, 5);
auto visualizer =
    make_operator<holoscan::ops::HolovizOp>("visualizer",
        Arg("cuda_stream_pool") = cuda_stream_pool);





std::shared_ptr<holoscan::ops::HolovizOp> visualizer =
    make_operator<ops::HolovizOp>("visualizer",
        Arg("enable_render_buffer_output", true),
        Arg("allocator") = make_resource<holoscan::UnboundedAllocator>("allocator"),
        Arg("cuda_stream_pool") = cuda_stream_pool);

add_flow(visualizer, destination, {{"render_buffer_output", "input"}});





visualizer = make_operator<ops::HolovizOp>(
            "holoviz",
            Arg("key_callback",
                ops::HolovizOp::KeyCallbackFunction([](ops::HolovizOp::Key key,
                                                       ops::HolovizOp::KeyAndButtonAction action,
                                                       ops::HolovizOp::KeyModifiers modifiers) -> void {
                HOLOSCAN_LOG_INFO(
                  "key {} action {} modifiers {}", int(key), int(action), *(uint32_t*)(&modifiers));
            }))
        )





def callback(
    key: HolovizOp.Key, action: HolovizOp.KeyAndButtonAction, modifiers: HolovizOp.KeyModifiers
):
    print(key, action, modifiers)

visualizer = HolovizOp(
            self,
            name="holoviz",
            key_callback=callback)





void key_callback(void *user_pointer, Key key, KeyAndButtonAction action, KeyModifiers modifiers) {
    ...
}
...
viz::SetKeyCallback(user_pointer, &key_callback);
...
